The end of the pin should be flush with the edge of the Plug Body. Twist on style attachment requires no special tooling Designed for attachment to RG58 coaxial cable Machined components produce a durable connector Gold plated contact pin reduces signal loss Associated bulk cable available Applications: Setting up the cable stripper may require some trial and error adjustment. Step 3 Installing a 2 Piece BNC Crimp type connector A crimp type connection allows for quick and simple installation while still maintaining a mechanical and electrical connection fairly close to a solder type termination. BNC connectors were commonly used on 10base2 thin Ethernet network cables and network cards.
Triaxial also known as triax connectors are a variant on BNC that carry a signal and guard as well as ground conductor.
BNC connectors are commonly used in electronics, but in some applications they are being replaced by LEMO 00 miniature connectors which allow for significantly higher densities. If the pin doesn't fit snugly against the insulation, remove it and trim the conductors until it does. Male 50 ohm BNC connector. Above this frequency, however, the mismatch becomes progressively more significant and can lead to signal reflections. Now when the pin is placed back on the conductor, its base should just reach the inner insulation band the center conductor should no longer be exposed.
